Compact industrial hooters and buzzers for panel-level fault indication, power failure alarms, and PLC-driven annunciators. 24V DC and 230V AC. Multi-tone. DIN rail and surface mount.
Panel hooters and buzzers are the most frequently purchased industrial alarm products in India — and also the most frequently mis-specified. A buzzer that sounds identical to the power-on confirmation tone, the fault alarm, and the trip alarm provides no meaningful diagnostic information to the operator. Correct panel hooter specification means distinct tones per alarm class, audibility above the panel room ambient noise, and reliable operation at the panel's DC bus voltage.
| Application | Model Type | Voltage | Output | Tones |
|---|---|---|---|---|
| MCC panel fault alarm | Electronic hooter, compact | 24V DC | 80–90 dB | 1–3 selectable |
| Control room annunciator | Electronic hooter, DIN rail | 24V DC / 110V AC | 85–95 dB | Multi-tone via contact |
| Power failure alarm | Electromechanical buzzer | 230V AC | 90–100 dB | Continuous / intermittent |
| Field panel, outdoor | Electronic hooter, IP55 housing | 24V DC / 230V AC | 95–105 dB | Multi-tone |
| Large control room | Horn speaker + amplifier | 230V AC | 105–110 dB | Via MT-PSH controller |
| Parameter | Specification |
|---|---|
| Output range | 80–110 dB depending on model |
| Supply voltage | 24V DC (standard), 12V DC, 110V AC, 230V AC — specify at order |
| Tone selection | Push button, DIP switch, or potential-free contact |
| Mounting | DIN rail, panel surface, conduit entry bottom or side |
| Enclosure | ABS or die-cast aluminium; IP55 for outdoor / field panel |
| Current draw | 50–300 mA at 24V DC depending on output level |
| Operating temp | −10°C to +60°C |
| Colour | Safety yellow (standard); red, grey on request |
When ordering a panel hooter, tell us: supply voltage (24V DC / 230V AC), required dB output, whether tones need to be selectable via contact inputs, mounting type (DIN rail / panel surface), and IP rating needed. This determines the exact model — a wrong specification here wastes time on both sides.
Available in 12V DC, 24V DC, 110V AC, and 230V AC. Powers directly from MCC bus bar without separate transformer.
Wire separate PLC outputs to different contact inputs — each triggers a distinct tone. Operator identifies fault class by sound alone.
Die-cast aluminium body, IP55, suitable for outdoor panel enclosures. Same tone, same reliability, weatherproof build.
Tell us your application, ambient noise level, coverage distance, and PLC brand. We'll respond within one working day with the right model and price.
