Genuine PESO and CIMFR certified flameproof hooters for explosive atmospheres. Not just weatherproof — certified explosion-proof for petroleum zones, paint booths, gas storage, and chemical plant areas.
An IP65 rated standard hooter is not permitted in a Zone 1 or Zone 2 hazardous area. IP65 means weatherproof — it does not mean explosion-proof. In a Zone 1 or Zone 2 area, standard electrical equipment is an ignition source. You must use a hooter that carries genuine PESO and CIMFR certification with Ex d (flameproof enclosure) or Ex e (increased safety) designation. Substituting a weatherproof hooter in a hazardous area is a safety violation and an insurance liability.
| Parameter | Specification |
|---|---|
| Certification | PESO and CIMFR certified — genuine certification documents supplied with each unit |
| Zone classification | Zone 1 and Zone 2 (IEC 60079 / IS 5780) |
| Ex designation | Ex d IIC T6 (flameproof enclosure) — suitable for most petroleum and chemical area classifications |
| Power supply | 24V DC / 230V AC / 415V AC — specify at order |
| Output | 95–110 dB at 1m |
| Enclosure | Copper-free cast aluminium, flameproof, IP66 |
| Cable entry | Flameproof cable gland, M20 or M25 — specify conduit size |
| Tone | Steady / intermittent / warbling — selectable by internal link |
| Operating temp | −20°C to +60°C |
| Applications | Petroleum depots, refineries, paint booths, solvent handling, gas cylinder stores, FPSO vessels, chemical plants |
| Zone | Definition | Required Certification |
|---|---|---|
| Zone 0 | Explosive atmosphere continuously present | Ex ia or Ex ma — contact us for specialist supply |
| Zone 1 | Explosive atmosphere likely during normal operation | Ex d (flameproof) or Ex e (increased safety) — our standard flameproof hooter |
| Zone 2 | Explosive atmosphere unlikely but possible | Ex d or Ex n — our standard flameproof hooter covers this |
| Safe Area | No explosive atmosphere | Standard hooter — no PESO/CIMFR required |
Every flameproof hooter we supply comes with: PESO certificate copy, CIMFR test certificate copy, zone classification confirmation letter, and installation guidelines for hazardous area wiring. These documents are required for your factory HSE file and for OISD/ERDMP compliance audits.
Not self-certified. PESO certificate issued by Petroleum and Explosives Safety Organisation. CIMFR test report from Central Institute of Mining & Fuel Research. Copies supplied with every unit.
24V DC for battery-backed panels and DCS loops. 230V AC single phase. 415V AC three phase for direct connection to plant bus. Specify at order — no modification needed.
Cast aluminium body — copper-free alloy as required for IIC gas group compatibility. No zinc or magnesium alloy body substitutes.
Tell us your application, ambient noise level, coverage distance, and PLC brand. We'll respond within one working day with the right model and price.
